BLUETOOTH SERIAL ADAPTER
0,00 zł
The Solexy SWA/SWS B The Solexy SWA/ SWS B** is a compact, cost-efficient solution for wireless serial data transmission in hazardous areas, where direct connection or disconnection of serial ports is typically not possible.
BLUETOOTH SERIAL ADAPTER – Product Card
Advantages:
- Replacement for RS232 and RS485/422 serial cables, based on Bluetooth V2.0 + EDR.
- Allows up to four simultaneous connections and supports the SPP (Serial Port Profile) Bluetooth protocol, ensuring compatibility with PDAs, laptops, and other devices.
- User-friendly Windows configuration tool included — no external drivers needed.
- Explosion-proof housing available in aluminum (SWA series) or stainless steel (SWS series), with weather protection rated IP66/68.
- Equipped with a Class 1 Bluetooth radio, enabling wireless communication over distances up to 100 m (328 ft).
| Power supply | 5 – 12 VDC |
| Power consumption | min. 2 mA – maks. 80 mA |
| Ambient temp. range | ATEX & IECEx SWA series -40°C do +85°C SWS series -40°C do +85°C SWA series -40°C do +83°C SWS series -40°C do +82°C |
| Weight | SWABxx03: 2,3 kg (without antenna) SWSBxx03: 4,9 kg (without antenna) |
| Serial speed | Up to 921.6 kbps |
| CTR/RTS i DTR/DSR | CTR/RTS flow control DTR/DSR for loop-back & full transfer (RS232 only) |
| Weight | SWABxx03: 2,3 kg (without antenna) SWSBxx03: 4,9 kg (without antenna) |
|---|---|
| EX zone classification |
